Khoom Paub meej
|
Qhov Chaw Keeb Kwm: |
Zhejiang, Suav teb |
|
Hom Lub Npe: |
jorch |
|
Specification: |
1.5series poj niam 6 tus pin connector |
|
Qauv nab npawb: |
DJ7061Y-1 8-21 |
|
OEM Tshooj NO: |
282090-1 |
|
Hom: |
Adapter |
|
Pin: |
6 pin |
|
Xim: |
Dub |
|
Txiv neej los yog poj niam: |
Poj niam |
|
Hom Connector: |
Muab kaw |
|
Ntawv pov thawj: |
TUV, TS16949, ISO14001 System thiab RoHS |
|
MOQ: |
Kev txiav txim me me tuaj yeem txais |
|
Lub sij hawm xa tuaj: |
Muaj peev xwm txaus thiab muaj peev xwm ntau lawm kom ntseeg tau raws sijhawm |
|
Tsim Muaj peev xwm: |
Peb tuaj yeem muab cov qauv, OEM & ODM Zoo siab txais tos. Customized Drawing Nrog Decal, Frosted, Sau Muaj Raws li thov |
automotive connector 282090-1 yog cov khoom siv dav siv hauv tsheb. Hauv qab no yog cov ncauj lus kom ntxaws qhia txog lub connector:
Basic tsis
- Qauv: 282090-1
- Hom: plug/socket
- Hom interface: AC / DC
- Tus lej ntawm daim npav txhawb nqa: tag nrho-hauv-ib
- Daim npav nyeem ntawv hom: CF
- Cov qauv tsim: rectangular
- Manufacturing txheej txheem: txias nias, thiab lwm yam.
- Keeb kwm: tej zaum yuav suav nrog Shanghai, thiab lwm yam.
Hluav taws xob thiab mechanical yam ntxwv
- Ua haujlwm voltage: VDC 24V (nominal voltage architecture suav nrog 12V, 24V)
- Ua haujlwm zaus: 1MHz
- Ua haujlwm kub ntau: -40 degree txog 125 degree (-40 degree F txog 257 degree F)
- Cov lej: 6
- Number ntawm kab: 1
- Terminal hom: poj niam davhlau ya nyob twg
- Terminal loj: 1.5mm
- Txiv neej dav dav dav: 1.5mm
- Center kab (ntu): 6mm
- Khoom siab: txog 32.2mm
- Khoom ntev: txog 36.8mm
- Khoom dav: txog 36.8mm (Ceeb Toom: Lwm cov ntaub ntawv qhia tias qhov ntev yog 3.1mm, qhov dav yog 4.8mm, thiab qhov siab yog 2.4mm, uas tej zaum yuav muaj feem xyuam rau cov khoom sib txawv lossis cov qauv tshwj xeeb)
Waterproof thiab sealing kev ua tau zoo
- Cov dej tsis sib haum: tuaj yeem ncav cuag IP67 lossis siab dua (nyob ntawm daim ntawv thov scenario thiab txoj kev teeb tsa)
- Sealing khoom: silicone roj hmab foob (hais hauv qee cov ntaub ntawv)
- Daim ntawv thov scenario: haum rau automotive hluav taws xob cov khoom sib txuas hauv cov av ntub lossis dej ib puag ncig kom ntseeg tau tias muaj kev nyab xeeb thiab ruaj khov ntawm cov khoom siv.
Daim ntawv thov thiab Compatibility
- Daim ntawv thov cov cheeb tsam: Feem ntau yog siv rau tsheb board-kawg kev sib txuas, haum rau ntau lub tsheb qauv, tuaj yeem hloov kho thiab hloov kho raws li qhov xav tau ntawm cov qauv sib txawv
- Compatibility: Zoo compatibility nrog rau lwm yam automotive connector khoom, thiab tej zaum kuj yuav sib xws nrog ib co lwm tus neeg connector khoom (tshwj xeeb kev pom zoo raws li qhov tseeb kuaj)
Cov ntawv pov thawj zoo thiab cov qauv
- Daim ntawv pov thawj zoo: Cov khoom ua tau raws li cov qauv zoo thiab cov ntawv pov thawj yuav tsum tau ua kom zoo thiab kev ntseeg siab
- Cov qauv kev lag luam: Ua tau raws li cov txheej txheem thoob ntiaj teb xws li UL (cov qauv tshwj xeeb yuav txawv nyob ntawm cov khoom lag luam thiab cheeb tsam)
Cov ntaub ntawv muab khoom siv
Cov tswv yim yuav khoom: Nws raug nquahu kom xaiv cov channel raws cai thaum yuav khoom, thiab ua tib zoo xyuas cov qauv khoom, cov lus qhia tshwj xeeb thiab cov ntaub ntawv pov thawj kom ntseeg tau tias koj yuav cov khoom tiag thiab txaus siab rau cov kev pabcuam tomqab muag.
Cov ntsiab lus
Automotive connector 282090-1 yog cov khoom siv hluav taws xob zoo sib txuas nrog cov khoom siv hluav taws xob zoo thiab cov khoom siv hluav taws xob zoo, cov dej tsis zoo thiab sealing kev ua tau zoo, thiab kev siv dav dav. Cov khoom no muaj dav daim ntawv thov kev cia siab thiab kev lag luam xav tau nyob rau hauv automotive teb.
